Immediate Despatch

100kW Fluid Chiller

Our 100kW chiller is a powerful and reliable fluid chiller designed to provide industrial and commercial applications with large volumes of chilled water โ€“ reducing temperatures to as low as -5ยฐC. The easily portable unit is mounted on robust base plates, making it easy and convenient to be transported and positioned with minimal disruption. When connected to your existing cooling system or used in combination with any air handling unit from our range, this environmentally friendly unit has the ability to provide large volumes of cooling and heating at a low power consumption. The 100kW chiller can operate unattended and is perfect for providing climate control to large volume spaces, including body storage applications, hospitals and server rooms.

Key Features

Feature

Feature

Lifting frame

facilitates transport and deployment

Low temperature capability

down to as low as -5ฬŠC

Quiet operation

low noise level of 58 dBA @ 10 metres

Economical

reducing running costs

Fast connecting line couplings

for simple and fast installation

Provides both heating and cooling

for all year-round use

Fully portable

can be positioned more easily

Robust construction

will stand up to the rigours of industrial use

Product Specification

Additional information

Nominal cooling duty

100 kW

Power supply

415 V 3 ph N+E 50 Hz Run 60 A

Plug type

BS4343 63 A 5 pin

Noise level (max)

58 dBA @ 10 metres

Weight

1,560 kg

Dimensions (L x W x H)

3090 x 1330 x 2775 mm

Control

Automatic programmer

Average power consumption

18 kW/h

Generator size

75 kVA

Water connection

50 mm (2") bauer

Nominal water flow

5 l/s

Accessories

10M EXT LEAD 5 PIN 63A 415V 25MM DIA
20M EXT LEAD 5 PIN 63A 415V 25MM DIA
6M X 50MM HOSE WITH BAUER COUPLINGS (2โ€)
FAN COILS/ AHU’S
MANIFOLDS
SYSTEM CONNECTION FITTINGS
PLATE HEAT EXCHANGER
REMOTE CHANGE OVER (HEAT PUMP ONLY)

Environments

Body storage
Process cooling
Manufacturing and industry
Hotels and resorts
Emergency chillers
Marquees
Building and construction
Pharmaceuticals
Hospitals and healthcare
